Powder Water-soluble Fertilizer Production Line
The powder water-soluble fertilizer production line is an automated
equipment system designed for producing water-soluble powdered
fertilizers, suitable for agriculture, horticulture, and other
industries. Its main function is to process various solid raw
materials through crushing and mixing procedures to create
high-quality powdered water-soluble fertilizers.
Production Process
1.Raw Material Preparation:
Select standard-compliant macronutrients (such as ammonium nitrate,
phosphate, potassium sulfate), micronutrients (such as boron, zinc,
iron, copper, manganese, molybdenum), and other auxiliary materials
(such as anti-caking agents, solubilizers).
2.Pretreatment
For raw materials, especially mineral-based ones, use a crusher to
pulverize them to a certain particle size for better mixing and
improved solubility.
Screen the crushed materials using a vibrating screen to remove
oversized particles and impurities, resulting in fine, uniform
powder.
3.Measuring
Accurately weigh each raw material according to the pre-designed
fertilizer formula to ensure the nutrient ratios of the final
product are correct.
4.Mixing
Add the various raw materials into a mixer in the specified
proportions. Use mechanical stirring to ensure thorough and uniform
mixing, ensuring consistent nutrient content in every batch of
fertilizer.
5.Quality Control and Packaging
Perform sample testing on the produced powdered water-soluble
fertilizer to confirm its solubility, nutrient content, pH value,
and other standards.
Package the qualified product in specified weights using
moisture-proof and light-resistant materials to ensure the
fertilizer’s stability during storage and transportation.
Features
1. The system adopts computer PLC control system with high degree
of automation and labor saving.
2. The main body adopts three-dimensional structure closed design,
quick installation connection, less material storage, no blockage,
easy to clean.
3. Equipped with dust removal facilities and dust-free packaging,
in line with environmental assessment requirements.
4. The back end of the system can be equipped with automatic
packaging, boxing and palletizing equipment.
